EPA5006GAT: 802.3at/af Gigabit Power-over-Ethernet Adapter

$28.99
 por
In stock!
Spend $75.00 to FREE SHIPPING
Earn 1 Point on this purchase. Learn more
Ver todos los detalles

EPA5006GAT: 802.3at/af Gigabit Power-over-Ethernet Adapter

$28.99
 por

Delivers Data & Power to PoE-Compliant Devices

The EnGenius EPA5006GAT PoE Adapter supports high-speed data and up to 30 watts of power to compliant devices such as APs, IP cameras or VoIP phones to 328-feet away over a single cable. A compact optimal port design provides easy, precise installation, while built-in power surge protection preserves valuable equipment.


- EPA5006GAT Datasheet


Shipping & Returns

Not satisfied? We allow returns within 30 days of product purchase

Great for Outdoor WiFi

Delivers both data and power to EnGenius outdoor access points

Flexible Deployment

Extends power to unwired areas up to 328-ft./100m away

Features

Overview

In-the-Box

Mounting

EPA5006GAT

Specifications

Product Highlights

  • Gigabit Ethernet In & Out Ports for High-Speed Devices

  • Disconnect, Short-Circuit & Surge Protection Ensure Reliable, Secure Connection

  • Mounts to Walls or Ceilings with Included Hardware

Technical Specifications

Standards
802.3 10BaseT
802.3u 100BaseT
802.3ab Gigabit Ethernet
802.3at/af Power-over-Ethernet

Compliance
FCC Part 15 Class B
IEC 60950-1:2005+A1
UL60950-1 2nd
CE
ENS55032:2012/AC:2013
EN55024:2010
RCM
AS/NZS60950.1: 2011/Amdt 1: 2012

Physical Interface
(1) Gigabit Data Port
(1) Gigabit Data & Power Output Port
(1) IEC 320C6 AC Connector

LED Indicator
1 x Power on Green

Mounting
Wall (anchors & screws included)

Power

Input Voltage
100 to 240VAC

Input Current
0.8A Max for 120VAC

AC Input Frequency
50-60Hz

Maximum Output Power
30W

Power Lines
Pin4(Vdc+)&Pin5(Vdc+)
Pin7(Vdc-)&Pin8(Vdc-)

Data Specifications
10/100/1000 Mbit/s
Pin1(Rx+)&Pin2(Rx-)
Pin3(Tx+)&Pin6(Tx-)

Added Protection Features
Short-Circuit
Surge (over current/over voltage)

Surge Protection
L-L: 2KV
L-G: 4KV

ESD Protection
Contact: 4KV
Air: 8 KV

Environmental & Physical

Temperature Range
Operating: 32°F to 104°F (0°C to 40°C)
Storage: -22°F to 176°F (-30°C to 80°C)

Humidity (non-condensing)
Operating: 5 to 90% or less
Storage: 5 to 90% or less

Dimensions & Weights

EPA5006GAT Device (Without Mounting Kit)
Weight: .33 lbs. (154 g)
Length: 3.9” (100 mm)
Width: 2.27” (58.5 mm)
Height: 1.3” (33.4 mm)

Package Contents
EPA5006GAT
Power Cord
