SFP3313-20A: SFP+ Switch 10Gig Transceiver Module
Earn [points_amount] when you buy this item.
SFP3313-20A: SFP+ Switch 10Gig Transceiver Module
10G Single Mode 20km
EnGenius SFP3313-20A SFP plus Transceivers are hot-swappable multi-purpose optical modules that support 10 Gigabit Ethernet applications across most switching and routing platforms. The transceivers support operating at 10Gbps serial optical data transfer rates on a single duplex fiber core with a length of up to 20,000m, ideally suited for data centers, enterprise and storage area networks.
Shipping & Returns
Not satisfied? We allow returns within 30 days of product purchase
20 Kilometers
Allows network connections of up to 20 kilometer distance
10 Gbps
10G SFP+ Single Mode Fiber at 1,330nm TX and 1,270nm RX Wavelengths
Specifications
- High Quality 10Gbase SFP plus transceiver
- IEEE 802.3az compliant
- Hot-swappable LC Duplex connector
- Low power dissipation
- Class 1 laser product, complies with International Safety Standard IEC 825
- ROHS Compliant
Standard Compliance
IEEE 802.3ae 10Gbase-LR
Data Rate Gigabit
10.3125G
Media Type
SMF
Max Transmission Distance
20km
Connector
Duplex LC Connector
Single / Bi-Directional
Bi-Direction
Average Output Optical Transmission Power
-8.2 ~ -0.5 dBm
Optical Receiver Sensitivity
-20 dBm
Wavelength
TX: 1330nm
RX:1270nm
Cable Type
Single mode
Supply Voltage
3V ~3.6V
Max Voltage/Current
3.45V/300mA
Maximum Receiver Power
-14.1 dBm
Temperature
Operating: 0°C ~70°C (32°F ~158°F)
Storage:-40°C ~85°C (-40°F ~185°F)
Humidity
5~95% (non-condensing)
Dimensions (Lx W x H)
2.26” x 0.55” x 0.43” (57.5mm x 14mm x 10.8mm)
Weight
0.06 lb. (25g)
Certification
Compliant with Class 1 Laser International Safety Standard with EN 60825-1
