E5-NB08: Industrial Edge AI Platform

Name: E5-NB08: Industrial Edge AI Platform
Brand: EnGenius Store
SKU: E5-NB08
Price: 1879.0 USD
Availability: InStock

$1,879.00

View full details

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Powered by NVIDIA® Jetson Orin™ NX 8GB, balancing performance and deployment flexibility for industrial AI applications

The E5-NB08 delivers the ideal balance of AI performance, scalability, and deployment flexibility. Built on NVIDIA® Jetson Orin™ NX 8GB, it empowers organizations to deploy intelligent vision applications across industrial automation, smart cities, transportation, and security with reliable real-time edge computing.

- AI Box Datasheet
- AI Box Quick Start Guide

Real-Time AI Performance

NVIDIA® Jetson Orin™ SoM streamlines intensive AI workloads at the source of data generation while maintaining low-power efficiency and compact footprint.

Rugged Fanless Design

Engineered for reliable 24/7 operation in harsh industrial environments, withstanding extreme temperatures, dust, and airborne particulates.

Rich IoT Connectivity

Ensures versatile I/O compatibility with both modern and legacy systems, sensors, and equipment.

Button

Buy Now

Features

E5-NB08

Specifications

Product Highlights

NVIDIA® Jetson Orin™ NX 8GB AI Platform

Up to 117 TOPS AI Performance

Bluetooth 5.2 Connectivity

Dual Gigabit Ethernet

Rich Industrial Interfaces

NVIDIA® Operation System L4T inside

Fanless Design with Wide Temperature
Support

Technical

6-core Arm Cortex-A78AE, up to 2.0GHz

8GB LPDDR5 memory

256GB NVMe SSD storage

Dual Gigabit Ethernet and Bluetooth 5.2
connectivity

Fanless industrial design, operating from
-20°C to 70°C

Mechanical

Mounting: VESA / DIN Rail / Wall Mount

Dimensions: 170 × 125 × 60 mm

Weight: 1.9kg

Button

Overview

Specifications	AI Box 157/157W	AI Box 117/117W	AI Box 67/67W
Processor	NVIDIA® Jetson Orin™ NX 16GB LPDDR5	NVIDIA® Jetson Orin™ NX 8GB LPDDR5	NVIDIA® Jetson Orin™ Nano 8GB LPDDR5
Storage	1 × M.2 M-key 2280 Default 256GB	1 × M.2 M-key 2280 Default 256GB	1 × M.2 M-key 2280 Default 256GB
Expansion Slots	1 × M.2 M-key 2280 (Optional Storage) 1 × M.2 E-Key 2230 (Optional Wi-Fi/Bluetooth)	1 × M.2 M-key 2280 (Optional Storage) 1 × M.2 E-Key 2230 (Optional Wi-Fi/Bluetooth)	1 × M.2 M-key 2280 (Optional Storage) 1 × M.2 E-Key 2230 (Optional Wi-Fi/Bluetooth)
I/O	2 × GbE LAN 2 × USB 3.2 2 × USB 2.0 1× DB9 CAN Bus 1 × DB25 GPIO 2 × DB9 Serial Ports 1 × HDMI Port (Screw Lock)	2 × GbE LAN 2 × USB 3.2 2 × USB 2.0 1 × DB9 CAN Bus 1 × DB25 GPIO 2 × DB9 Serial Ports 1 × HDMI Port (Screw Lock)	2 × GbE LAN 2 × USB 3.2 2 × USB 2.0 1 × DB9 CAN Bus 1 × DB25 GPIO 2 × DB9 Serial Ports 1 × HDMI Port (Screw Lock)
Operating System	NVIDIA® Linux L4T NVIDIA® JetPack 6.2 Support	NVIDIA® Linux L4T NVIDIA® JetPack 6.2 Support	NVIDIA® Linux L4T NVIDIA® JetPack 6.2 Support
Operating Temperature	−20°C to 70°C	−20°C to 70°C	−20°C to 70°C
Dimensions	170 × 125 × 62.5 mm	170 × 125 × 62.5 mm	170 × 125 × 62.5 mm
